HARTING 21348400585100

Description

American Wire Gauge: 22 AWG

Number of Cores: 5

Standards Met: IEC 61076-2-101, ISO/IEC 11 801, ISO/IEC 24 702, RoHS Compliant

Cable Shape: Multicore

IP Rating: IP67

Shielded/Unshielded: Unshielded

Maximum Operating Temperature: +80°C

Operating Temperature Range: -25 → +80 °C

Connector 1 Orientation: Straight

Connector 1 Gender: Male

Length: 10m

Sheath Material: Polyvinyl Chloride PVC

Series: 2134 Connector 1 Housing Gender: Male Connector 1 Number of Contacts: 5 Coding: A Sheath Colour: Grey Cross Sectional Area: 0.34 mm² Minimum Operating Temperature: -25°C Connector 2: Unterminated Connector 1: M12 1st Connector Orientation: A 2nd Connector Mounting Type: – HTSUS: 8544.42.9090 RoHS Status: ROHS3 Compliant Usage: Industrial Environments Shielding: Unshielded 1st Connector Number of Positions Loaded: All 1st Connector Shell Size – Insert: M12 REACH Status: REACH Unaffected edacadModel: 21348400585100 Models Cable Material: Polyvinyl Chloride (PVC) 2nd Connector Type: Wire Leads edacadModelUrl: /en/models/8034907 Assembly Configuration: Standard 2nd Connector Number of Positions: – 2nd Connector Number of Positions Loaded: – Manufacturer: HARTING Moisture Sensitivity Level (MSL): Not Applicable Length: 32.8′ (10.00m) 1st Connector Gender: Male Pins standardLeadTime: 8 Weeks 1st Connector Type: Receptacle 2nd Connector Shell Size – Insert: – 1st Connector Number of Positions: 5 Ingress Protection: IP67 – Dust Tight, Waterproof Color: Gray Series: M12 2nd Connector Orientation: – Cable Type: Round Packaging: Bulk 2nd Connector Gender: – 1st Connector Mounting Type: Free Hanging (In-Line) ECCN: EAR99

This ismanufactured by HARTING. The manufacturer part number is 21348400585100. Features 22 awg – American Wire Gauge. The product consists of 5 cores. The product complies with all safety standards, such as iec 61076-2-101, iso/iec 11 801, iso/iec 24 702, rohs compliant. Moreover, this cable has a multicore shape. It is IP rated with ip67. Moreover, the product is unshielded . It has a maximum operating temperature of +80°c. The product has -25 → +80 °c of operating temperature range. The connector 1 has a straight orientation. This connector 1 is a male. Its accurate length is 10m. The sheath is constructed from durable and adorable polyvinyl chloride pvc material. The product 2134, is a highly preferred choice for users. On the other hand, the gender of connector 1’s housing is male. There are 5 contacts on connector 1. The product is coded with a. The sheath has an adorable grey colour. The product has 0.34 mm² cross section area. Whereas, the minimum operating temperature of the product is -25°c. While the Connector 2 is unterminated. Connector 1 is m12. This connector has a a orientation. It is assigned with possible HTSUS value of 8544.42.9090. The product is rohs3 compliant. The product’s typical Applications include uses in industrial environments. Furthermore, the product is shielded with unshielded. While the loaded positions on first connector are all. The size of the first connector’s shell – insert is m12. In addition, it is reach unaffected. The cable is constructed from highly durable polyvinyl chloride (pvc) materials. The second connector is the wire leads. The product is designed in a standard assembly configuration. The harting’s product offers user-desired applications. Its typical moisture sensitivity level is not applicable. Its accurate length is 32.8′ (10.00m). The first connectors are male pins. It has a long 8 weeks standard lead time. receptacle is the first connector. The first connector contains 5 positions. It is IP rated with ip67 – dust tight, waterproof. It has a classic gray colour. The product m12, is a highly preferred choice for users. It is a typical round cable. In addition, bulk is the available packaging type of the product. The first connector is configured with a free hanging (in-line) mounting type. The product is designated with the ear99 code number.
