DPDT relay ultra high sensitive,2A 12Vdc

Description

Dimensions: 10 x 6 x 5.65mm

Coil Voltage: 12V dc

Application: Signal

Terminal Type: Through Hole

Coil Resistance: 2800Ω

Coil Power: 50mW

Maximum Switching Voltage DC: 220V dc

Maximum Switching Power DC: 60 W

Isolation Coil To Contact: 1kV ac

Maximum Operating Temperature: +85°C

Switching Current: 2A

Operating Temperature Range: -40 → +85°C

Latching: No Contact Configuration: DPDT Length: 10mm Features: Bifurcated Contacts, Low Coil Power Consumption Mounting Type: PCB Mount Series: IM Depth: 6mm Height: 5.65mm Maximum Switching Current DC: 2 A Maximum Switching Voltage AC: 250V ac Minimum Operating Temperature: -40°C Maximum Switching Power AC: 62.5VA Number of Poles: 2 Contact Material: Gold Plated HTSUS: 8536.41.0050 Package: Tube Series: * RoHS Status: RoHS CompliantECCN: EAR99

This is DPDT relay ultra high sensitive2A 12Vdc manufactured by TE Connectivity. The manufacturer part number is IM26TS. The given dimensions of the product include 10 x 6 x 5.65mm. The coil voltage of the product is 12v dc. Applications Information involves signal. The terminal is a through hole type. It holds up to 2800ω coil resistance. Robust coil power of 50mw. While it carries 220v dc of maximum DC switching voltage. It bears a maximum 60 w of DC switching power. The product has 1kv ac isolation coil to contact. It has a maximum operating temperature of +85°c. It is integrated with 2a switching current. The product has -40 → +85°c of operating temperature range. Latching Options – no. The contact is equipped with dpdt configuration. Its accurate length is 10mm. The splendid features of the product include bifurcated contacts, low coil power consumption. The product is available in pcb mount configuration. The product im, is a highly preferred choice for users. The product comes in 6mm depth. In addition, the height is 5.65mm. It has a minimum 2 a DC switching current . It has a maximum AC switching voltage of 250v ac. Whereas, the minimum operating temperature of the product is -40°c. It also features an AC switching power of 62.5va. It has equipped with 2 poles. The product is made from sturdy gold plated materials. It is assigned with possible HTSUS value of 8536.41.0050. It is shipped in tube package . The product is rohs compliant. The product is designated with the ear99 code number.
