Description
Operating Force: 1.27 N
Dimensions: 6 x 13.8mm
Mounting Type: Through Hole
Operating Temperature Range: -25 → +70°C
Contact Current Rating: 50 mA @ 24 V dc
Minimum Operating Temperature: -25°C
Contact Configuration: SPST
Width: 13.8mm
Length: 6mm
Actuator Type: Button
Mechanical Life: 3000000Operations
Maximum Operating Temperature: +70°C
Terminal Type: Through Hole
This is Button Tactile Switch SPST 50 mA @ 24 V dc Through Hole manufactured by Omron. The manufacturer part number is B3F-8000. It has a 1.27 n of operating force. The given dimensions of the product include 6 x 13.8mm. The product is available in through hole configuration. The product has -25 → +70°c of operating temperature range. The rated contact current is 50 ma @ 24 v dc. Whereas, the minimum operating temperature of the product is -25°c. The contact is equipped with spst configuration. Furthermore, the product is 13.8mm wide. Its accurate length is 6mm. The product carries button actuator. The product also provide mechanical stability with 3000000operations. It has a maximum operating temperature of +70°c. The terminal is a through hole type.
