SWITCH, TOGGLE ON-ON, 1 POLE 20A Mil Spe

Description

Actuator Length: 17mm

Illuminated: No

Mounting Type: Bushing

Voltage Rating: 125 V ac, 250 V ac, 277V ac

Contact Current Rating: 15 A

Panel Cut Out Diameter: 12.4mm

Minimum Operating Temperature: -65°C

Operating Temperature Range: -65 → +71°C

Panel Cut Out Size: 12.4 (Dia.) x 11.4mm

Contact Configuration: SPDT

Panel Cut Out Width: 11.4mm

Switch Operation: On-On

Maximum Operating Temperature: +71°C Terminal Type: Screw Contact Material: Silver Alloy, Gold Plated

This is SWITCH TOGGLE ON-ON 1 POLE 20A Mil Spe manufactured by Honeywell. The manufacturer part number is 1TL1-3. The actuator is a 17mm long. Illumination Option no. The product is available in bushing configuration. Moreover, the product has a nominal 125 v ac, 250 v ac, 277v ac voltage rating. The rated contact current is 15 a. The panel has a 12.4mm cut-out diameter. Whereas, the minimum operating temperature of the product is -65°c. The product has -65 → +71°c of operating temperature range. The panel cut out size includes 12.4 (dia.) x 11.4mm. The contact is equipped with spdt configuration. Its panel cut out is 11.4mm wide . It provides on-on switch operation. It has a maximum operating temperature of +71°c. The terminal is a screw type. The product is made from sturdy silver alloy, gold plated materials.
