Recom RXXP06S 1W Isolated DC-DC Converter Through Hole, Vin 10.8 → 13.2 V dc, Vout 6V dc, I/O isolation 6.4kV dc

Description

Number of Outputs: 1

Load Regulation: ±15%

Isolation Voltage: 6.4kV dc

Efficiency: 81%

Mounting Type: Through Hole

Package: SIP7

Maximum Temperature: +90°C

Series: RxxP06S

Input Voltage Range: 10.8 → 13.2 V dc

Length: 19.5mm

Isolated: Yes

Width: 9.8mm

Depth: 12.5mm Output Voltage: 6V dc Minimum Temperature: -40°C Input Voltage Nominal: 12 V dc Power Rating: 1W Output Current: 167mA Standards Met: CAN/CSA-C22.2 No.62368-1-14, CB Report, cRUus, IEC/EN 60950-1, IEC/EN 62368-1, IECEE CB SCHEME, UL 62368-1

This is RXXP06S 1W Isolated DC-DC Converter Through Hole Vin 10.8 → 13.2 V dc Vout 6V dc I/O isolation 6.4kV dc manufactured by Recom. The manufacturer part number is R12P06S. Additionally, the product is supplied with 1 outputs. Load Regulation – ±15%. It has 6.4kv dc isolation voltage. It is a highly efficient product with an 81% of high efficiency. The product is available in through hole configuration. It is shipped in sip7 package . The product has +90°c maximum temperature. The product rxxp06s, is a highly preferred choice for users. It has 10.8 → 13.2 v dc of input voltage range. Its accurate length is 19.5mm. Isolated options – yes. Furthermore, the product is 9.8mm wide. The product comes in 12.5mm depth. Features a 6v dc output voltage. While its minimum temperature is -40°c. It has 12 v dc of nominal input voltage. Feature 1w of power rating. It carries 167ma output current. The product complies with all safety standards, such as can/csa-c22.2 no.62368-1-14, cb report, cruus, iec/en 60950-1, iec/en 62368-1, iecee cb scheme, ul 62368-1.
